GT-14AH Night Vision Monocular

GT-14AH Night Vision Monocular

  • Generation 3 Auto-Gated Image Intensifier, Hand Select Alpha
  • Thin Filmed, Green Phosphor

$3,110

The GT-14 is a high-performance night vision monocular with advanced ergonomics and intelligent power control developed as an alternative to the standard PVS-14. Submersible and lightweight, GT-14 is equipped with the most advanced, U.S. made Generation 3 image intensifier tubes.

N-Vision Optics’ GT-14 can be used hand-held, head or helmet mounted, weapon mounted, or even dual mounted for use in a binocular configuration. All GT-14 units are equipped with automatic brightness control (ABC) and in-ocular IR and Low Battery indicators.

Each unit ships with: GT-14 adapter (j-arm), sacrificial window, eyecup, lens cap, neckcord, soft carry case, lens cleaning paper, battery, user manual.

Features
  • Submersible and shockproof
  • Automatic brightness control (ABC)
  • Invisible to the human eye IR
  • Hand-held, helmet-mountable, weapon-mountable
  • In ocular IR-on and low battery indicators
Specifications
Magnification

1x

Range Focus

25 cm to infinity

Diopter Focus

-6 to +2

Field of View

40˚

Operating Temperature

-51˚ C to +49˚C

Storage Temperature

-51˚ C to +85˚C

Weight

320 g / 11 oz

Battery

1 CR123 or 1 AA

Image Intensifier

Generation 3 Hand Select Alpha Auto-Gated Image Intensifier

Resolution

64 lp/mm (min)

Signal to Noise

25 (minimum)

Dark Spots
Size

Zone 1

Zone 2

Zone 3

>.009-.012

0

0

0

>.006-.009

0

0

2

>.003-.006

0

0

3
