G15AH Night Vision Binocular
G15AH Night Vision Binocular
- Auto-Gated Generation 3 Image Intensifier, Hand Select Alpha
- Thin Filmed, Green Phosphor
- Dual Tube Configuration
$6,050
The G15 is a dual tube night vision binocular designed for use in situations where increased situational awareness and depth perception are critical. Dual tube binocular night vision systems provide increased depth perception in comparison to monocular systems. This feature affords the user enhanced capabilities to perform mission essential tasks such as driving and administering first aid.
Ideal for head or helmet mounted and observatory operations, the G15 is built from two GT-14 monoculars which are dual mounted and may be separated for independent use which makes the G15 a truly versatile night vision device.
Each unit ships with: sacrificial window (2), eyecup (2), lens cap (2), neckcord, soft carry case, lens cleaning paper, battery, user manual.
- Improved depth perception
- Hand held or mounted on head or helmet
- Automatic brightness control (ABC)
- Submersible and shockproof
Accessories
Magnification | 1x | ||
---|---|---|---|
Range Focus | 25 cm to infinity | ||
Diopter Focus | -6 to +2 | ||
Field of View | 40˚ | ||
Operating Temperature | -51˚ C to +49˚C | ||
Storage Temperature | -51˚ C to +85˚C | ||
Weight | 748 g/ 26 oz | ||
Battery | 2 CR123 or 2 AA | ||
Image Intensifier | Generation 3 Alpha Auto-Gated Image Intensifier | ||
Resolution | 64 lp/mm (min) | ||
Signal to Noise | 25 (minimum) | ||
Dark Spots | |||
Size | Zone 1 | Zone 2 | Zone 3 |
>.009-.012 | 0 | 0 | 0 |
>.006-.009 | 0 | 0 | 2 |
>.003-.006 | 0 | 0 | 3 |
