G15AH Night Vision Binocular

G15AH Night Vision Binocular

Auto-Gated Generation 3 Image Intensifier, Hand Select Alpha
Thin Filmed, Green Phosphor
Dual Tube Configuration

$6,050

Add to Cart

Description Accessories Specifications Similar products Downloads

The G15 is a dual tube night vision binocular designed for use in situations where increased situational awareness and depth perception are critical. Dual tube binocular night vision systems provide increased depth perception in comparison to monocular systems. This feature affords the user enhanced capabilities to perform mission essential tasks such as driving and administering first aid.

Ideal for head or helmet mounted and observatory operations, the G15 is built from two GT-14 monoculars which are dual mounted and may be separated for independent use which makes the G15 a truly versatile night vision device.

Each unit ships with: sacrificial window (2), eyecup (2), lens cap (2), neckcord, soft carry case, lens cleaning paper, battery, user manual.

Features

Improved depth perception
Hand held or mounted on head or helmet
Automatic brightness control (ABC)
Submersible and shockproof

Eye Cup

5x Magnifier Lens

Helmet Mount Assembly

3x Magnifier Lens

Purge Kit, Night Vision

Magnification	1x
Range Focus	25 cm to infinity
Diopter Focus	-6 to +2
Field of View	40˚
Operating Temperature	-51˚ C to +49˚C
Storage Temperature	-51˚ C to +85˚C
Weight	748 g/ 26 oz
Battery	2 CR123 or 2 AA
Image Intensifier	Generation 3 Alpha Auto-Gated Image Intensifier
Resolution	64 lp/mm (min)
Signal to Noise	25 (minimum)
Dark Spots
Size	Zone 1	Zone 2	Zone 3
>.009-.012	0	0	0
>.006-.009	0	0	2
>.003-.006	0	0	3
